GitOps with ArgoCD and Flux CD Explained

GitOps with ArgoCD and Flux CD represents one of the most significant shifts in Kubernetes delivery practices. The core idea is elegant: your Git repository is the single source of truth for the desired state of your cluster. Any change — whether a new deployment, a config map update, or a Helm chart version bump — goes through a pull request, gets reviewed, and is automatically applied to the cluster. No more kubectl apply from a local machine.

What is GitOps and Why It Matters

GitOps is a set of practices where the entire system state is versioned in Git and an automated operator continuously reconciles the cluster to match it. The four principles defined by OpenGitOps are: declarative configuration, versioned and immutable state, pulled automatically (the cluster pulls from Git, not CI pushes to the cluster), and continuously reconciled. This approach eliminates configuration drift, makes rollbacks as simple as reverting a commit, and creates a full audit trail of every infrastructure change.

ArgoCD: UI-first GitOps for Kubernetes

ArgoCD is a pull-based continuous delivery tool that runs inside your Kubernetes cluster and watches Git repositories for changes. It ships with a rich web UI and CLI that show you exactly which resources are in sync and which have drifted from the desired state. ArgoCD supports Helm, Kustomize, jsonnet, and plain YAML — making it adaptable to any repo structure.

# ArgoCD Application manifest
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: my-app
  namespace: argocd
spec:
  project: default
  source:
    repoURL: https://github.com/myorg/my-app-config.git
    targetRevision: HEAD
    path: k8s/overlays/production
  destination:
    server: https://kubernetes.default.svc
    namespace: production
  syncPolicy:
    automated:
      prune: true      # Remove resources deleted from Git
      selfHeal: true   # Revert manual changes in cluster
    syncOptions:
      - CreateNamespace=true

Flux CD: The CNCF-Graduated Alternative

Flux CD takes a more GitOps-native approach: instead of a monolithic operator, it's a collection of Kubernetes controllers — the source controller, kustomize controller, helm controller, notification controller, and image automation controller. Each controller watches its own custom resource and reconciles independently. Flux integrates tightly with Kustomize and supports multi-tenancy through namespace isolation.

Flux GitRepository and Kustomization Resources

In Flux, you define a GitRepository resource that points to your config repo and specifies a polling interval. The Kustomization resource then references that GitRepository, specifies the path to apply, and declares health checks. Flux will continuously sync the cluster to match the manifests in that path, pruning resources that are removed from Git.

# Flux CD — GitRepository + Kustomization
apiVersion: source.toolkit.fluxcd.io/v1
kind: GitRepository
metadata:
  name: my-app
  namespace: flux-system
spec:
  interval: 1m
  url: https://github.com/myorg/my-app-config
  ref:
    branch: main
---
apiVersion: kustomize.toolkit.fluxcd.io/v1
kind: Kustomization
metadata:
  name: my-app
  namespace: flux-system
spec:
  interval: 10m
  path: ./k8s/production
  prune: true
  sourceRef:
    kind: GitRepository
    name: my-app
  healthChecks:
    - apiVersion: apps/v1
      kind: Deployment
      name: my-app
      namespace: production

Automated Image Updates

Both ArgoCD and Flux support automated image tag updates — a critical feature for teams that want fully automated delivery. When a new container image is pushed to a registry, the image automation controller updates the image tag in your Git config repo, which triggers a sync and deploys the new version. This creates a complete, Git-driven delivery loop without any manual steps.

Flux Image Updater Configuration

Flux's image automation controllers use two resources: an ImageRepository that polls a container registry on an interval, and an ImagePolicy that selects which tags to promote based on semver ranges, alphabetical ordering, or regex patterns. A third resource, ImageUpdateAutomation, commits the updated tag back to Git — completing the loop.

# Image Updater — auto-update image tags from a registry
apiVersion: image.toolkit.fluxcd.io/v1beta2
kind: ImageRepository
metadata:
  name: my-app
  namespace: flux-system
spec:
  image: ghcr.io/myorg/my-app
  interval: 5m
---
apiVersion: image.toolkit.fluxcd.io/v1beta2
kind: ImagePolicy
metadata:
  name: my-app
  namespace: flux-system
spec:
  imageRepositoryRef:
    name: my-app
  policy:
    semver:
      range: ">=1.0.0"   # Only promote semver releases

ArgoCD vs Flux: Which Should You Choose?

ArgoCD is the better choice if you want a rich UI, RBAC-controlled multi-cluster management, and a single-pane-of-glass view of all your applications. Flux is the better choice if you prefer a lightweight, controller-based approach that fits naturally into existing Kubernetes tooling, or if you need strong multi-tenancy and GitOps automation at scale. Both are CNCF projects with strong communities — the 'best' choice depends on your team's preferences.

GitOps Terminology Explained

GitOps introduces some new vocabulary alongside familiar Kubernetes terms: GitOps, ArgoCD, Flux CD, Kustomize, and Helm.

To get started with GitOps in production: begin with a single non-critical application, use Kustomize overlays to manage environment differences, set up Slack notifications for sync events and health status changes, and implement branch protection on your config repo so all changes require a PR review. Gradually expand GitOps to cover your entire cluster as your team builds confidence in the workflow.
