How database replication works: WAL shipping, sync versus async commit trade-offs, failover, split-brain, and when multi-leader or leaderless makes sense.
Matthews Wong
Software Engineer
Key Takeaway
Database replication copies every change from one leader to one or more followers, usually by shipping the write-ahead log. Asynchronous replication commits fast but can lose the newest writes at failover. Synchronous replication waits for a follower, trading latency for durability. Fencing and quorum voting prevent split-brain, where two nodes both claim leadership.
The question that made me read the replication chapter properly was a boring one: if the Postgres container behind a point-of-sale system dies in the middle of a shift, what exactly is lost? The answer turned out to depend on one setting and on a second server that most small deployments do not have.
This post explains leader-follower replication from the log up, then the commit trade-off, failover, split-brain, and the two other topologies. Every setting comes from the PostgreSQL documentation, the other claims from the Dynamo paper and Wikipedia, and every number in the worked examples is either quoted or shown as arithmetic on stated assumptions. I did not benchmark anything for this post.
In leader-follower replication (also called primary-standby or master-replica), one node accepts all writes and one or more followers receive a copy of every change. Teams add followers for three separate reasons, and it matters which one you are buying.
The mechanism underneath is the write-ahead log. PostgreSQL's central rule is that changes to data files must be written only after the WAL records describing them have been flushed to permanent storage, which is what lets it recover after a crash by replaying the log. A follower does the same replay continuously, fed over the network instead of from local disk. The configuration below is the minimum for a streaming standby with a replication slot and a quorum of one.
# --- primary: postgresql.conf ---
wal_level = replica # enough WAL detail for physical replicas
max_wal_senders = 5 # one slot per connected standby, plus headroom
max_replication_slots = 5 # the primary keeps WAL until each slot has it
synchronous_commit = on # the default; only bites once standbys are named
synchronous_standby_names = 'ANY 1 (replica_a, replica_b)'
# quorum: any ONE of the two must confirm
# --- primary: pg_hba.conf ---
# the special database name "replication" is how a standby is allowed in
host replication replicator 10.0.0.0/24 scram-sha-256
# --- standby: postgresql.conf (plus an empty standby.signal file) ---
primary_conninfo = 'host=10.0.0.10 user=replicator application_name=replica_a'
primary_slot_name = 'replica_a_slot'There are two transports. File-based log shipping copies finished WAL segment files to the standby; the documentation notes this is asynchronous by definition, because records are shipped after the transaction commits, so there is a data-loss window that archive_timeout can shrink to a few seconds at the cost of bandwidth. Streaming replication instead has the standby connect to the primary, which sends WAL records as they are generated without waiting for a file to fill.
Streaming is asynchronous by default, and the documentation describes the delay as typically under one second when the standby is powerful enough to keep up. Two operational details bite people. Without a replication slot or a large enough wal_keep_size, the primary may recycle WAL before a slow standby has received it, and that standby must then be rebuilt from a fresh base backup. With a slot, the opposite risk appears: the primary keeps WAL until the standby catches up, so a dead standby can fill the disk. Lag is measured by comparing pg_current_wal_lsn on the primary with the standby's received position.
-- On the primary: how far behind is each standby, in bytes of WAL?
SELECT application_name,
sync_state, -- async | sync | potential | quorum
pg_wal_lsn_diff(pg_current_wal_lsn(), replay_lsn) AS replay_lag_bytes
FROM pg_stat_replication;
-- On a standby: has it received everything the primary has written?
SELECT pg_last_wal_receive_lsn(), pg_last_wal_replay_lsn();
-- Per transaction, not per server: a cheap audit-log write can skip the wait.
BEGIN;
SET LOCAL synchronous_commit TO off; -- this commit will not wait for any standby
INSERT INTO page_view_log (path) VALUES ('/blog/replication');
COMMIT;A physical standby replays the same byte-level changes as the primary, so it must run the same major version and cannot hold extra tables. Logical replication, which streams row changes and allows version jumps, is a different tool; I covered that angle in the zero-downtime upgrade post.
The commit trade-off is a single question: when the client receives success, where does the data already live? PostgreSQL's synchronous_commit setting answers it in levels, and it only reaches the standby once synchronous_standby_names is non-empty.
| synchronous_commit | Success returned after | What it survives |
|---|---|---|
| off | No wait at all for the WAL flush | Nothing guaranteed for the last moments; the documented maximum delay is three times wal_writer_delay, though the database stays consistent |
| local | Local WAL flush on the primary only | A primary process crash; not the loss of the primary machine |
| remote_write | Standby received the record and wrote it to its operating system | A PostgreSQL crash on the standby, not an operating-system crash there |
| on (default) | Standby flushed the record to durable storage | Loss only if the primary and all synchronous standbys lose their storage |
| remote_apply | Standby replayed the record, so queries on it can see the data | Same as on, plus reads on the standby that see your own writes |
The price of waiting is latency, and it is simple arithmetic. The numbers below are assumptions chosen to be round, not measurements; substitute your own fsync and round-trip times.
Assumed inputs (illustrative, measure your own):
local WAL fsync = 1.0 ms
network round trip = 0.5 ms (same region)
standby WAL fsync = 1.0 ms
synchronous_commit = local -> 1.0 ms per commit
synchronous_commit = on -> 1.0 + 0.5 + 1.0 = 2.5 ms per commit
(the commit record is flushed locally first, then sent; the primary
waits for the standby's flush acknowledgement)
One connection committing serially:
local : 1000 ms / 1.0 ms = 1000 commits per second
on : 1000 ms / 2.5 ms = 400 commits per second
Async data-loss window (assumed): WAL written at 2 MB/s, standby 1.5 s behind
2 MB/s x 1.5 s = 3 MB of committed WAL that dies with the primary
Quorum arithmetic (majority = floor(N / 2) + 1):
N = 3 -> majority 2 (survives 1 failure, can tell a minority side apart)
N = 2 -> majority 2 (survives 0 failures: a partition leaves nobody sure)
Leaderless (Dynamo style), N = 3 replicas:
W = 2, R = 2 -> R + W = 4 > 3, every read overlaps the latest write
W = 1, R = 1 -> R + W = 2 <= 3, a read can miss the newest valueThe setting is per transaction, not per server. A payment commit can wait for a standby while a page-view log insert uses SET LOCAL synchronous_commit TO off, which is the cheapest way to avoid paying 2.5 ms where durability does not matter. One more property to design around: with synchronous replication, commits may never complete if a required synchronous standby crashes, so name several candidates and use FIRST or ANY rather than a single named standby.
Synchronous replication turns a standby outage into a primary outage unless you configured spare candidates. If the only synchronous standby dies, writes block until you reduce the requirement and reload the configuration. Decide in advance which direction you want to fail: stopped writes or lost writes.
Failover is the act of promoting a follower after the leader fails. PostgreSQL deliberately does not include the software that detects the failure; the documentation says that many external tools exist for it, so detection and IP migration are your tooling's job, not the database's. The sequence is the same whichever tool runs it.
The documentation is blunt about the cost of an asynchronous failover: some committed transactions may not have reached the standby, and the data loss is proportional to the replication delay at the moment of failover. With the assumed 2 MB per second of WAL and a 1.5 second lag from the worked example, that is about 3 MB of acknowledged writes that the application believes are saved.
Split-brain happens when a partition or a false failure leaves two nodes both believing they are the leader, so each accepts writes the other never sees. The Wikipedia article describes the pessimistic remedy as a quorum: the partition holding a majority of votes stays available while the others fall back to auto-fencing. The PostgreSQL failover chapter names the other half, STONITH (shoot the other node in the head), as the mechanism that tells a restarted old primary it is no longer the primary.
The arithmetic explains why three nodes are the practical minimum. A majority of N is floor(N / 2) + 1, so three nodes tolerate one failure and the surviving pair can outvote the isolated one. Two nodes need two votes, so a partition leaves neither side sure; Wikipedia puts the chance that a two-node cluster without a witness fails entirely at no less than 50 percent until a human intervenes. PostgreSQL's own documentation mentions a witness server for this reason while warning that the extra complexity needs careful testing.
Synchronous quorum settings help from the data side. With ANY 1 of two named standbys, a promoted standby is guaranteed to hold every acknowledged commit, because at least one of them confirmed each one. Quorum protects the data; fencing protects against two writers. You need both.
Prefer failing closed. A leader that stops accepting writes when it loses contact with a majority is annoying for a minute; a leader that keeps writing on the wrong side of a partition is a reconciliation project for a week.
Leader-follower is the default because it has exactly one writer and therefore no write conflicts. The two alternatives remove that single writer and pay for it elsewhere.
| Topology | Who accepts writes | Conflicts | Typical fit |
|---|---|---|---|
| Leader-follower | One leader | None on writes; followers can lag on reads | Most application databases, including ERP and POS back ends |
| Multi-leader | A leader per site or per node | Concurrent edits must be detected and resolved | Several regions that each need local writes, or offline-capable clients |
| Leaderless | Any replica, using R and W quorums | Resolved on read or by vector clocks and application logic | Always-writable key-value workloads such as the Dynamo shopping cart |
Leaderless systems use quorum arithmetic instead of a leader. In the Dynamo paper, with N replicas, a write waits for W acknowledgements and a read for R responses, and choosing R plus W greater than N makes read and write sets overlap. With N of 3, W of 2 and R of 2 gives 4, which is greater than 3, while W of 1 and R of 1 gives 2 and can return stale data. The paper also describes sloppy quorums and vector-clock reconciliation, which is the conflict handling that single-leader systems avoid by design.
For a business application on one Postgres instance, the honest starting point is single-leader streaming replication with one or two followers. Work through this checklist before adding anything more exotic.
On a single VPS, which is where my own ERP and POS work runs, the follower only earns its place if it lives elsewhere, and backups with point-in-time recovery cover much of the same risk at lower complexity. Multi-leader and leaderless designs are worth their conflict handling only when you genuinely need writes in several places at once.
A replica is a second copy plus a decision. The copy is the easy part, a stream of WAL. The decision is what a commit waits for, who is allowed to be leader, and how the old leader is stopped. Settle those three before the day you need them.
