Service mesh vs API gateway: north-south versus east-west traffic, sidecar versus ambient mesh, real nginx and Istio config, cost, and when you need neither.
Matthews Wong
Software Engineer
Key Takeaway
An API gateway handles north-south traffic: it sits at the edge, authenticates clients, rate limits and routes requests into your system. A service mesh handles east-west traffic: it adds mutual TLS, retries and telemetry between services through proxies. A small team on one server usually needs neither, only a reverse proxy.
Every few months someone asks whether a system needs Istio, and the honest first question is what problem they are trying to solve. The two tools get confused because both are proxies that route HTTP, both can enforce policy, and both show up in the same architecture diagrams.
This post separates them by the direction of the traffic they handle, shows a real nginx gateway config and real Istio YAML, checks the sidecar and ambient models against the Istio and Linkerd documentation, and ends with a decision checklist. My own systems are a Qilap-style ERP and POS on NestJS, Postgres and Redis in Docker on a single VPS, which is exactly the situation where the answer is usually neither.
North-south traffic crosses the boundary of your system: a browser, a mobile app or a partner calls in from outside. East-west traffic stays inside: the orders service calls the catalog service, a worker calls the billing API. The terms are network-diagram slang rather than a formal standard, but they map cleanly onto the two tools.
An API gateway owns north-south. It is the single front door where you terminate TLS, identify the caller, throttle abusive clients and decide which backend a path belongs to. A service mesh owns east-west. It assumes the caller is already inside and focuses on making every internal hop encrypted, observable and resilient without changing application code.
Gateway work is about outsiders: authentication of tokens or API keys, rate limiting, request routing by path or host, TLS termination, and sometimes response caching or request transformation. In its simplest form that is a reverse proxy. The nginx config below routes two path prefixes to two upstream groups and rate limits each client address, using the directives from the official limit_req documentation.
# /etc/nginx/conf.d/gateway.conf (north-south: the one door into the system)
# 10 requests/second per client IP on average, bursts of up to 20 extra.
limit_req_zone $binary_remote_addr zone=api:10m rate=10r/s;
limit_req_status 429; # default is 503, which reads like an outage
upstream orders_api { server 10.0.0.11:3001; server 10.0.0.12:3001; }
upstream catalog_api { server 10.0.0.21:3002; }
server {
listen 443 ssl;
server_name api.example.com;
location /orders/ {
limit_req zone=api burst=20 nodelay; # nodelay: serve the burst now
proxy_set_header X-Request-Id $request_id;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_pass http://orders_api/;
}
location /catalog/ {
limit_req zone=api burst=20 nodelay;
proxy_pass http://catalog_api/;
}
}The arithmetic is worth doing once. A rate of 10r/s with burst=20 and nodelay means a client averages 10 requests per second but can fire 20 extra immediately before being rejected with the 429 status; the nginx documentation notes the default rejection code is 503, which is why the config overrides it. Authentication usually sits in front of this block, either as a JWT check in the gateway or as an nginx subrequest to an auth service. The gateway pattern article linked at the end shows the NestJS version.
A mesh moves cross-cutting concerns for internal calls out of application code and into proxies: mutual TLS between workloads, retries and timeouts, traffic splitting for canary releases, and uniform metrics and traces. Istio expresses these as Kubernetes resources. The first policy refuses plaintext traffic inside one namespace, and the second adds a timeout, retries and a 90/10 canary split for the orders service.
# East-west: refuse any plaintext call between workloads in "shop".
apiVersion: security.istio.io/v1
kind: PeerAuthentication
metadata:
name: default # "default" = namespace-wide policy
namespace: shop
spec:
mtls:
mode: STRICT # PERMISSIVE accepts both; use it while migratingapiVersion: networking.istio.io/v1
kind: VirtualService
metadata:
name: orders
namespace: shop
spec:
hosts:
- orders.shop.svc.cluster.local
http:
- timeout: 5s
retries:
attempts: 3 # mesh-level retries
retryOn: "connect-failure,unavailable"
route:
- destination:
host: orders.shop.svc.cluster.local
subset: v2
weight: 10 # canary: 10 / (10 + 90) of traffic
- destination:
host: orders.shop.svc.cluster.local
subset: v1
weight: 90
---
# subsets must be declared here, or the VirtualService points at nothing
apiVersion: networking.istio.io/v1
kind: DestinationRule
metadata:
name: orders
namespace: shop
spec:
host: orders.shop.svc.cluster.local
subsets:
- name: v1
labels: { version: v1 }
- name: v2
labels: { version: v2 }Field names above follow the Istio reference pages for PeerAuthentication and VirtualService, where the documented default for retries is 2 attempts. Linkerd takes a narrower route: its documentation says it enables mutual TLS automatically for TCP traffic between meshed pods, with certificates bound to the pod ServiceAccount identity and expiring after 24 hours. Both approaches get you encrypted, identity-checked internal calls without touching service code.
Retries multiply. If your HTTP client retries 3 times and the mesh also retries 3 times, one failing user request can hit the broken service 9 times, and a gateway retry on top makes it 27. Pick one layer to own retries, and pair it with timeouts and backpressure so a struggling service is not buried by its own callers.
The classic mesh injects a proxy next to every application pod. Linkerd documents this as a data plane proxy in each pod, and Istio's sidecar mode uses an Envoy proxy the same way. Istio's ambient mode removes that per-pod proxy and splits the data plane into two layers, according to the Istio ambient overview:
Ambient is version-dependent: the Istio announcement for release 1.24 says its core components were marked Stable then. The overview page gives no overhead numbers, only that waypoints are heavier than ztunnel alone, so treat any claimed percentage saving as something to measure on your own cluster rather than a fact.
The table summarises where each tool sits and what it is for. Read the rows as a division of labour rather than a ranking, because most production systems that use both are using each for the job it is built for.
| Aspect | API gateway | Service mesh |
|---|---|---|
| Traffic direction | North-south, from clients into the system | East-west, between internal services |
| Where it runs | One or a few edge proxies | A proxy per pod (sidecar) or per node plus optional waypoints (ambient) |
| Authentication | Identifies external callers: tokens, API keys | Identifies workloads: mutual TLS identities |
| Rate limiting | Core feature, per client or key | Possible, but rarely the main reason to adopt a mesh |
| Resilience | Timeouts and upstream failover at the edge | Retries, timeouts and traffic splitting on every internal hop |
| Observability | Edge request logs and metrics | Uniform metrics and traces for every service-to-service call |
| Operational cost | Low: one config file can be enough | High: a control plane, proxy upgrades and new failure modes |
The overlap is real. A gateway can retry upstream calls and a mesh can rate limit, so the useful question is which layer should own a concern. Put anything about untrusted callers at the gateway, and anything about trusted internal hops in the mesh or, for a small system, in the application itself.
The cost is a count of moving parts you now operate. Take a hypothetical cluster of 12 services with 3 replicas each on 4 nodes in 2 namespaces. The sketch below shows how many proxies each model implies, and how stacked retries inflate load. The numbers are arithmetic on assumed inputs, not a benchmark.
// Hypothetical cluster: 12 services x 3 replicas on 4 nodes, 2 namespaces
pods = 12 * 3 // 36
sidecar proxies = pods // 36 (one Envoy per pod)
ambient L4 only = nodes // 4 (one ztunnel per node)
ambient + L7 = 4 + 2 // 6 (ztunnel per node + one waypoint per namespace)
// Retry stacking: client library x mesh
worst case calls per user request = 3 * 3 // 9 hits on the failing serviceSidecar mode gives 36 proxies to upgrade and restart alongside the apps, while ambient with waypoints gives 6, though those 6 are shared infrastructure with their own scaling. Either way you also run a control plane, learn a new set of resources, and debug failures where the proxy rather than your code is at fault. Service discovery, which another article in this series covers, is something you still need regardless of the mesh.
Adopt in stages. Start with PERMISSIVE mutual TLS, watch the traffic, then switch to STRICT per namespace. In ambient mode you can begin with the L4 ztunnel only and add a waypoint just for the namespaces that need L7 routing.
Usually not a mesh, and often not even a full gateway. A single VPS running a NestJS API, Postgres, Redis and a few workers in Docker has one real edge, and a reverse proxy handles it. Use this checklist before adding either tool:
If you answered yes only to the third question, you want a gateway. If the first answer is yes and the rest are no, you want a reverse proxy and good libraries, nothing more.
Yes, and this is the common arrangement in larger systems. The gateway receives the external request, validates the caller and forwards it with a request ID. From that point the mesh takes over, encrypting each internal hop and applying the retry and routing policy. The order to follow when adopting them is:
Kubernetes users can also model the edge with the Gateway API, which is covered in a separate comparison with Ingress. Some meshes can act as the edge gateway too, but keeping the two roles named separately keeps the policy easier to reason about.
The rule I carry is to choose by traffic direction. Untrusted callers entering the system need a gateway. Trusted services talking to each other need a mesh only once the repeated work across teams costs more than operating the proxies. Until then, a reverse proxy and disciplined libraries are the right size.
